3D BIM Rebar Shop Drawings
Rebar Fabrication

REBAR DETAILING SERVICE

WE PROVIDE REBAR DETAILING SERVICE FOR :

    - REBAR FABRICATORS,
    - CONCRETE CONTRACTORS,
    - MASONRY CONTRACTORS,

New York-based, in house detailing.
20 years of Experience on Rebar Detailing.


STANDARDS & CODES

  • ACI (American Concrete Institute),
  • CRSI (Concrete Reinforcing Steel Institute),
  • RSIC (Reinforcing Steel Institute of Canada),
  • BS (British Standards),
  • EN (European Code)

REBAR SHOP DRAWINGS:

Over the years, we discovered the best suitable shop drawings for everybody ’s need.
Easy to Read for the field to reduce installation time and Labor cost.

  • We work with RFI’s, We don’t make any assumptions,
  • Our drawings are Arc D 24”x36” paper size easy to carry at the field,
  • Each page includes a bending schedule,
  • Each Page includes a Lap Splice Tables,
  • Elevations for all the walls and beams,
  • All the details in the sections, concrete coverage, lap splices… etc.
  • Revision clouds for each revision,
  • Intelligent Bar Mark System,


        ADMIN:

  • Upload project files in our website. You can sign in and access all your documents. Once you contact us, we will provide you a user name and password.
  • Schedule in a calendar showing all your project and estimated completion time.
  • Detailed Submittal Log, for each page,
  • Rebar Weight Log for each revision for your change order,
  • Detailed Change order list for every revision
  • Any revision takes 1 hour or less on Us.
  • We Provide you bar list for each pour in any format you want pdf, asa, soule … etc.



        PROJECT ENGINEER  :

  • Review the drawings for missing information and produces RFI ’s,
  • Review the drawings and checks the Code requirements,
  • Make phone calls with Engineer of the record or contractors to reduce the time and eliminate the mistakes,


        Turn Around Time :

Usually one week for the first submittal.
Sorry, We don’t make a promise to get the job, but we make a promise to complete the Job with success!


Please send us an email if you have any questions kcabuk@haqqrebar.com
